Polaris P 15 OR [9/88] Description of water heater

Polaris P 15 UR [9/88] Description of water heater
Above-sink
Above-sink
Above-sink
Under-sink
Under-sink
Model 10 15 30
Theoretical weight kg: 6,6 7,4 12,8
7
GB
Description of water heater
(see fig. 7)
General remarks
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lak of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
Local regulations may provide restrictions for installation in bathrooms.
Installation is in charge of the purchaser the manufacturer cannot be held
responsible for the damages caused by wrong installation and for not
following instructions included in this pamphlet, particularly on:
1) The electric connection has to be in compliance with the relative para-
graphe.
2) The installation has to be carried out by qualified professional.
Installation instructions
The range of the water-heaters includes models prepared for being fitted
over or under the point of use (wash-basin, sink, shower). The models to
be fitted under the point of use called “sottolavello” (”under wash-basin”).
Fastening to the wall
Fasten the supporting bracket provided to the wall using screws and
rawlplugs of suitable dimensions for the type of wall.
Hook the water heater onto the bracket and pull it dowanwards to make
sure it has been fastened correctly.
Water
connection
Connect the water heater’s inlet and outlet with pipes or fittings that are
resistant to the working pressure as well as to the temperature of the hot
water that can usually reach and exceed 80° C. We therefore advise against
the use of materials that do not resist such high temperatures. Screw a “T”
piece union to the water heater inlet pipe with the bleu collar. On one side
F) Switch / Indicator light bulbs
A) Lower cover
M) Regulation handle
B) Water feeding pipe
C) Water outlet pipe
Technical data
For the technical characteristics of the appliance, please refer to the
information provided on the data plate (label located near the water inlet
and outlet pipes).
