Hotpoint-Ariston H6GG5F (X) [23/40] Start up and use

Using the hob

Lighting the burners

For each BURNER knob there is a complete ring

showing the strength of the flame for the relevant

burner.

To light one of the burners on the hob:

1. Bring a flame or gas lighter close to the burner.

2. Press the BURNER knob and turn it in an

anticlockwise direction so that it is pointing to the

maximum flame setting (.

3. Adjust the intensity of the flame to the desired

level by turning the BURNER knob in an

anticlockwise direction. This may be the minimum

setting &, the maximum setting ( or any position in

between the two.

If the appliance is fitted with

an electronic lighting

device* (

), press the

ignition button, marked with

the symbol



, then hold

the BURNER knob down

and turn it in an

anticlockwise direction, towards the maximum flame

setting, until the burner is lit.The burner may be

extinguished when the knob is released. If this

occurs, repeat the operation, holding the knob down

for a longer period of time.

! If the flame is accidentally extinguished, switch off

the burner and wait for at least 1 minute before

attempting to relight it.

If the appliance is equipped with a flame failure

safety device (X)*, press and hold the BURNER

knob for approximately 2-3 seconds to keep the

flame alight and to activate the device.

To switch the burner off, turn the knob until it reaches

the stop position

•.

Practical advice on using the burners

For the burners to work in the most efficient way

possible and to save on the amount of gas consumed,

it is recommended that only pans that have a lid and a

flat base are used. They should also be suited to the

size of the burner.

Start-up and use

Burner ø Cookware diameter (cm)

Fast

Semi Fast (S) 16 - 20

Auxiliary (A) 10 - 14

To identify the type of burner, please refer to the

diagrams contained in the “Burner and nozzle

specifications”.

! On the models supplied with a reducer shelf,

remember that this should be used only for the

auxiliary burner when you use casserole dishes with a

diameter under 12 cm.

Using the oven

! The first time you use your appliance, heat the

empty oven with its door closed at its maximum

temperature for at least half an hour. Ensure that the

room is well ventilated before switching the oven off

and opening the oven door. The appliance may emit a

slightly unpleasant odour caused by protective

substances used during the manufacturing process

burning away.

! Before operating the product, remove all plastic film

from the sides of the appliance.

! Never put objects directly on the bottom of the

oven; this will avoid the enamel coating being

damaged. Only use position 1 in the oven when

cooking with the rotisserie spit.

Lighting the oven

To light the oven burner, bring

a flame or gas lighter close to

opening F (

see figure

) and

press the OVEN control knob

while turning it in an

anticlockwise direction until it

reaches the MAX position.

If the appliance is fitted with an electronic lighting

device*, press the ignition button, marked with the

symbol



, then hold the OVEN control knob and

turn it in an anticlockwise direction, towards the MAX

position, until the burner is lit. If, after 15 seconds,

the burner is still not alight, release the knob, open

the oven door and wait for at least 1 minute before

trying to light it again. If there is no electricity the

burner may be lit using a flame or a lighter, as

described above.

Only available in certain models.

(UR)

24-26

Flame adjustment according to levels

the burner flame intensity can be adjusted with the

knob according to 6 power levels, from maximum

to minimum with 4 intermediate positions:

a click will indicate the change from one level to

another when turning the knob. The system

guarantees a more precise adjustment, allows

to replicate the flame intensity and to identify

easily the preferred level for different cooking

operations.
