- 38
Operating additional equipment
Sound from PC or Set Top Box
Feed the analogue audio signal from the PC or the STB to the sockets AUDIO IN
L/R on the TV via a cinch cable. The sound is reproduced via the TV speakers.
If you have connected a digital external audio amplifi er, you can select the
digital audio signal in the connection wizard (TV menu - Connections - New
devices/modifi cations) and assign it to the VGA/XGA socket. You can make the
other settings for the audio amplifi er as described for digital amplifi ers on page
36. The digital audio signal of the Set Top Box is fed in at the AUDIO DIGITAL IN
socket on the TV. Feed the digital audio signal from the TV AUDIO DIGITAL OUT
to the amplifi er.
Component video connection
If you have a DVD player/recorder with Component OUT connec-
tions, you can connect it to the SD/HD-COMPONENT IN sockets
of the TV instead of to the Euro-AV sockets. The connecting
cable with three cinch plugs each transmits picture information.
The playback is of a better quality than via the Euro-AV socket.
You need another cinch cable for the analogue sound transmission. Connect the
analogue audio outputs of the DVD player to the AUDIO IN L/R sockets on the
TV set. The sound is reproduced via the TV speakers.
If you want to use the digital sound of the DVD player with a digital audio
amplifi er connected to the TV, make a connection between AUDIO DIG OUT of
the DVD player and AUDIO DIGITAL IN of the TV set.
Log in the component/device in the connection wizard:
Assign the AUDIO DIG IN input here to the COMP. IN socket, provided a digital
audio amplifi er is also connected. You can make the other settings for the audio
amplifi er as described for digital amplifi ers on page 36.
Set the signal at the component input in the connection wizard: Set to "Auto-
matic" fi rst. If the signal is not reproduced when playback is started, consult
the operating instructions of the DVD device connected to fi nd out what screen
resolution is possible (SDTV, HDTV or ProScan).
Select the component connection in the AV selection.
Call AV selection
Select COMP. IN sockets and use ...
to call.
Start playback on the connected device.
Set geometry and colour standard: as described for the VGA/XGA connection.
OK
VIDEO
COMP. IN
AVS
VGA
DVD
D
MI/DVI
HDMI/D
V
AV selection
VCR
OK
OK
AV
