- 22
Operating additional equipment
Calling AV stations with the channel overview
Call the channel overview with the OK button in TV mode.
OK
MENU
0 9
END
OK
Channel overview
OK
Switch over
- Select station
3
3
3
3
12 WDR
13 BR
14 HR
15 MDR
16 ARTE
17 KIKA
18 PHOENIX
19 BR-ALPHA
20 3SAT
21 KABEL
22 CNN INT.
23 H O T
24 TV 5
25 TRT 1
AVS
AV2
AV1
0 VIDEO
1 ARD
2 ZDF
3 SAT.1
4 RTL
5 VOX
6 3SAT
7 S–RTL
8 N–TV
9 DSF
10 TM3
11 PRO7
Change programmes
You will always fi nd the AV sockets at the top of the list with-
out station numbers.
Select the AV socket.
OK
Call with OK.
OK
Now you will see the playback from the connected video device.
Search for and store the station of the video recorder (if no Euro AV
cable is available)
Switch on the test station on the VCR or insert a recorded tape and start play-
back. In some video recorders the station must be switched on by activating the
modulator.
Then call the AV selection on the TV set with 0 AV. Select the menu item “0
VIDEO“ in the AV selection and call with OK.
To prevent “normal” TV stations being found in the search, pull out the antenna
plug from the antenna input of the VCR temporarily (the cable to the antenna
system).
If you cannot see the test station or playback from the cassette, the VCR is
transmitting on a different channel. You then have to search for the station or
set it manually.
Call the TV menu with the MENU button.
Select the “Settings“ menu item with .
Select the line below it with and “Channels“ with .
Select the line below with and “Manual settings“ with and call this
menu with OK.
For models without DVB-T:
Select “UHF” in the “Range” menu item and enter “E30“ under the “Channel”
menu item.
For models with DVB-T:
Select “Antenna/Cable” in the “Signal source” menu item and enter “E30“
under the “Channel” menu item.
Start search with the blue button.
If the station has been found, enter the name VIDEO, confi rm with OK and
save with the red button.
A list of the stored stations is displayed.
Select 0 (VIDEO) here and overwrite this program place with the red button.
Hide the menu again with the MENU button.
Plug the antenna plug back in.
If you now get interference because a TV station is transmitting on the same
channel as the VCR station, you have to change the transmitting station on the
VCR and search for the VCR station on the TV again.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
