Loewe Xelos A 20 [24/28] Problem possible cause help
![Loewe Xelos A 20 [24/28] Problem possible cause help](/views2/1020463/page24/bg18.png)
- 24
What to do, if ...
Problem Possible cause Help
The device cannot be operated. Parental lock is activated. Deactivate the parental lock: In the TV menu - Settings
- switch off parental lock or enter secret code.
General problems with connecting external devices
via an AV input.
a) The AV standard is set incorrectly
b) The AV signal is set incorrectly
a) Set the standard correctly
b) Set the AV signal correctly
If “Automatic“ is set for AV standard or AV signal, this
can lead to faulty detection in the case of non-stand-
ardized signals. Then the standard and the signal must
be set according to the specifi cations in the operating
manual of the external device.
No sound via the TV loudspeakers. In the Sound menu - other the item “Sound via ...“
is not set to “TV“.
Change setting to “TV“.
All menus appear in the wrong language. Wrong menu language set. Press the INFO key while no menu is displayed. The
index appears.
Select the fi rst entry on the fi rst page (1/2), if it is not
selected automatically.
Confi rm with OK.
You are now in the language menu and can select your
language.
1.
2.
3.
Various characters are displayed incorrectly in
teletext.
The wrong character set is set in the Teletext
menu.
Set the correct character set: Teletext menu - Settings -
Character set - Standard or the appropriate character set.
