10
Childproof lock
The hob can be protected against being accidentally turned on,
to ensure that children do not switch on the hotplates.
Turning on and off the childproof lock.
The range should be turned off.
To turn on: press the
D symbol for approx. 4 seconds. The
indicator next to the
D symbol lights up for 10 seconds. The
range is locked.
To turn off: press the
D symbol for approx. 4 seconds. The
range is unlocked.
Note: The childproof lock can be accidentally activated by the
presence of water spilled while cleaning, food that has spilled
over or objects resting on the
D symbol.
Activating and deactivating the childproof
lock
With this function, the childproof lock automatically activates
when a hob is switched off.
Activating and deactivating
See the “Basic Settings" section.
Powerboost function
The Powerboost function can be used to heat food more
quickly than using the power level
Š.
All the hotplates have this function.
To activate
The hob must be switched on, but no hotplate should be
working.
1. Select the required hotplate.
2. Select the power level Š.
3. Then press the + symbol.
The
› symbol lights up in the display. The powerboost
function has been activated.
Note: If any hotplate is switched on when the Powerboost
function is working, › and Š will flash on the hotplate display;
the power level
Š will then be set. The Powerboost function will
be deactivated.
To turn off
Select the hotplate and press the - symbol. The › indicator will
no longer be displayed and the hotplate will return to the power
level
Š. The Powerboost function has been deactivated.
Note: In certain circumstances, the Powerboost function may
turn off automatically in order to protect the electronic
components inside the hob.
Broil**
Steaks, chops (plain or breaded)
Beefsteak (3 cm thick)
Chicken breast (2 cm thick)
Fish and fish fillet without breading
Fish and fish fillet with breading
Prawns and shrimps
Frozen meals (e.g., stir-fries)
Pancakes
Omelette
6-7
7-8
5-6
5-6
6-7
7-8
6-7
6-7
3.-4.
Frying** (150-200g per serving with 1-2 l. of oil)
Frozen foods (e.g., French fries, chicken nuggets)
Frozen croquettes
Meatballs
Meat (e.g., chicken pieces)
Fish, vegetables, breaded or battered, e.g., mushrooms
Confectionary products (e.g., fritters, fruit in batter)
8-9
7-8
7-8
6-7
6-7
4-5
Power level
* Uncovered cooking
** Uncovered
