12
To access the basic settings
The range should be turned off.
1. Turn on the range with the main switch.
2. Within the next 10 seconds, press the D symbol and hold
for 4 seconds.
™‚ appears in the lower display.
3. Press the D several times until the required setting indicator
appears.
4. Then select the required setting using the + and - symbols.
The setting appears on the upper right of the display.
5. Press the D symbol again and hold it for 4 seconds. The
settings have been properly saved.
Quit
To leave the basic settings, turn off the hob at the main switch.
Care and cleaning
The advice and warnings contained in this section aim to guide
you in cleaning and maintaining the hob, so that it is kept in the
best possible condition
Hob
Cleaning
Clean the hob after each use. This prevents food remains left
on the surface from burning. Wait until the hob is cold enough
before attempting to clean it.
Only use cleaning products specifically designed for glass-
ceramic hobs. Follow the instructions provided on the
packaging.
Do not use:
■ Abrasive products
■ heavy-duty cleaners, like oven sprays and stain removers
■ Pads that may scratch
■ High-pressure or steam cleaners
Glass scraper
Remove dried-on food remains using a glass scraper.
1. Release the scraper safety catch
2. Use the blade to clean the hob surface
Do not attempt to clean the hob surface with the base of the
scraper. This could result in scratching.
m Risk of injury!!
The blade is extremely sharp. Risk of cuts. Protect the blade
when not in use. Replace the blade immediately when any
imperfections are found.
Care of the appliance
Apply an additive to protect and preserve the hob. Follow the
advice and warnings provided with the product.
Hob frame
In order to avoid damage to the hob frame, follow the
indications below:
■ Use only slightly soapy hot water
■ Do not use sharp or abrasive products
■ Do not use a glass scraper
™ˆ
Power-Management function
‹ = Deactivated.*
‚ = 1,000 W. minimum power.
‚ = 1,500 W.
ƒ = 2,000 W.
etc.
Š or Š. = maximum power of hob.**
™‹
Return to basic settings
‹ Personal settings.*
‚ Return to factory settings.
Indicator Function
*Factory settings
**The hob's maximum power depends on the configuration of the installation's connection intensity. To not exceed this maximum
value, the hob includes a series of components that automatically control the power, distributing it between the hotplates in use
as required.
