49-EN
01GB06IVAW200.fm
ALPINE IVA-W200 68-04123Z67-A (EN)
Multi-Changer Selection (Optional)
When using KCA-410C (Versatile Link Terminal), you can connect two
changers.
1
In changer mode, touch [CHG SEL] or press BAND
on the remote control (supplied) to select the next
changer (connected CD changers or KCA-420i).
2
To operate the selected changer, see “CD/MP3/
WMA” section.
• To operate the selected changer, see “CD/MP3/WMA” (pages 14-
16).
Listening to Music of HDD
This device is controllable from the unit when Alpine HDD player is
connected.
1
Touch [SOURCE] on the main source screen.
The source selection screen appears.
2
Touch [MM DRIVER].
The MM DRIVER mode main screen appears.
3
Select the desired music by touching [] or
[].
Searching: Touch [] or [].
Fast-forward/reverse: Touch and hold [] or [].
4
Touch [/] to temporarily stop the music
currently playing.
Touch [/] again to resume the play.
HDD Player
Operation
(Optional)
01GB00IVAW200.book Page 49 Tuesday, December 20, 2005 11:41 AM
