![JBL OnBeat Xtreme [12/13] Specifications](/views2/1205402/page12/bgc.png)
12
trOuBleshOOtIng Bluetooth paIrIng
Symptom Possible Problem Solution Note
The audio device does not pair with the
JBL OnBeat Xtreme
The audio device is not compatible with
the JBL OnBeat Xtreme unit.
Verify compatibility with manufacturer.
The JBL OnBeat Xtreme unit is not
powered on.
Press the Power button on the
JBL OnBeat Xtreme system.
The Power button glows white when the
unit is on.
The JBL OnBeat Xtreme source is not in
Bluetooth pairing mode.
Press the Source Select button until it
flashes blue.
The Source Select button flashes blue
when it is in pairing mode and glows blue
when it is in Bluetooth mode.
Bluetooth-enabled device’s battery is low. Recharge the device’s battery following
the instructions in its user manual.
specIFIcatIOns
Compatibility*
(docking):
iPad WiFi + 3G, iPad Wi-Fi
®
, iPad 2 WiFi+3G, iPad 2
WiFi, docking versions of the iPod (including iPod nano
6th generation, iPod nano 5th generation, iPod touch 3rd
generation, iPod touch 2nd generation, iPod nano 4th
generation, iPod classic, iPod touch 1st generation, iPod
nano 3rd generation, iPhone 4, iPhone 3GS, iPhone 3G,
iPhone
Transducers:
Two x JBL Atlas™ woofers and two JBL Ridge tweeters
Amplifier power:
30W x 2 (woofers); 15W x 2 (tweeters)
Frequency
response:
47Hz – 22kHz
Signal-to-noise ratio: 85dB
Input impedance
(Aux input):
>15k ohms
Input connections:
Main connection – iPod and iPhone docking connector;
Aux input connection – 3.5mm (1/8") stereo mini jack
Power requirement:
100V – 240V AC, 50Hz/60Hz
Power consumption:
120W (maximum); 0.5W (Eco-Standby mode)
Dimensions
(H x D x W):
9" x 9-5/8" x 17-1/2" (230mm x 244mm x 445mm)
Weight:
8.9 lb (4kg)
* Compatibility at time of writing. For the latest compatibility information,
visit www.jbl.com
0299CSK - JBL OnBeat Xtreme OM EN (New from Harman) v2.indd 12 04/08/11 11:01:28
