usIng yOur JBl OnBeat XtreMe

CONTROLS

Power Button

Volume Up/Down Buttons

Source Select Button

Bluetooth Button

Power button: The Power button has several functions:

• When the JBL OnBeat Xtreme is in the Sleep mode, press the Power

button for less than two seconds to turn the system on. The Power

Button LED will glow white.

• When the JBL OnBeat Xtreme is on, press the Power button for less than

two seconds to place the system in the Sleep mode. The Power Button

LED will glow amber. While in the Sleep mode, the system remains

paired with a Bluetooth device, and the system will automatically turn

on if a paired Bluetooth device receives a phone call.

• When the JBL OnBeat Xtreme is on, press the Power button for more

than two seconds to place the system in the Eco-Standby mode. The

Power Button LED will turn off. While in the Eco-Standby mode, the

Bluetooth module is turned off to minimize power consumption. NOTE:

The JBL OnBeat Xtreme will not automatically enter the Eco-Standby

mode.

NOTE: Pressing the Power button will also place a docked device into its

sleep mode. When listening to a docked device, the JBL OnBeat Xtreme

will automatically enter the sleep mode whenever no control buttons have

been pressed and no audio signal has been present for 10 minutes.

Volume Up/Down buttons: Press these buttons to raise and lower

the volume. Press both buttons simultaneously to mute or unmute the

volume.

Source Select button: Press this button to cycle through the audio

sources: Bluetooth, iPod/iPhone/iPad dock, Auxiliary input. The Source

Select LED changes color to indicate which audio source is selected.

See Power and Source Select LEDs on page 9.

Bluetooth button: Press this button to answer a phone call and perform

other Bluetooth functions. See Bluetooth Pairing, on page 6; and

Receiving a Phone Call from a Bluetooth-enabled Device, and Placing a

Phone Call from a Bluetooth-enabled Device, on page 7.
