ПРАВИЛА ЭКСПЛУАТАЦИИ
• Включайте прибор в сеть с напряжением 220 В.
• Отключайте прибор от сети после использования и перед чисткой.
• Перед тем как отключить прибор от сети, нажмите кнопку "OFF" ВЫКЛ. на панели управления или
на пульте ДУ.
• Чтобы избежать опасности удара электрическим током, не погружайте прибор в воду или другие
жидкости и следите, чтобы на него не попадала вода.
• Храните прибор в приспособленном для этого месте.
• Не оставляйте без присмотра включенный в сеть прибор.
• Не оставляйте прибор без присмотра вблизи детей, инвалидов, домашних животных.
• Используйте прибор строго по назначению, как указано в инструкции.
• Не пользуйтесь прибором, если у него повреждены шнур или вилка, или его уронили.
• Устанавливайте вентилятор на ровную устойчивую поверхность.
• Не касайтесь вращающихся частей во время работы вентилятора.
• Следите, чтобы посторонние предметы не попадали в отверстия прибора или в его решетки.
• Не блокируйте вентиляционные отверстия на корпусе мотора.
• Не пользуйтесь вентилятором без решеток.
СБОРКА ВЕНТИЛЯТОРА
Этап 1:
Вставьте нижнюю часть основания (12) в подставку (13) до тех пор, пока нарезной конец
стойки полностью не войдет в отверстие. Закрепите соединение стойки и подставки, плотно закрутив
гайку (14) для крепления нижней части основания на нарезной части стойки.
Этап 2:
Установите верхнюю выдвижную трубку (11) в нижнюю часть основания (12) и закрепите его
с помощью винта (10).
Этап 3:
Установите заднюю решетку (7) на кожух двигателя (9). Следите, чтобы выступы на корпусе
мотора совпали с отверстиями на решетке. Закрепите решетку гайкой (6).
Этап 4:
Наденьте лопасть вентилятора (5) на вал (8) двигателя. Убедитесь, что стержень вала
двигателя совпадает с пазом в центре задней части лопасти вентилятора. Закрепите лопасть
вентилятора на валу двигателя, плотно затянув фиксатор лопасти вентилятора (4).
Этап 5:
Совместите переднюю решетку (1) с задней (7), выровняйте вершины решеток. Оденьте на
них обод (3). Закрутите винт (2) в отверстие на ободе.
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
Этап 1:
Установите подставку для вентилятора на сухую и ровную поверхность.
Этап 2: Подключите провод к стандартной розетке переменного тока напряжением 220 В.
Этап 3: Вставьте 2 батарейки типа AA в специальный отсек пульта дистанционного управления в
соответствии со схемой, изображенной внутри пульта.
СКОРОСТНЫЕ РЕЖИМЫ РАБОТЫ
Для регулировки скорости воздушного потока нажмите кнопку ON/SPEED на контрольной панели
вентилятора или на пульте ДУ:
1 низкая скорость вращения;
2 средняя скорость вращения;
3 высокая скорость вращения.
SWING (ВРАЩЕНИЕ)
Возможна работа в стационарном положении и с поворотом на 90°.
Для того чтобы головная часть вентилятора начала вращаться, нажмите кнопку ВРАЩЕНИЕ (SWING) на
пульте дистанционного управления или кнопку на контрольной панели вентилятора. Для того чтобы
остановить вращение, нажмите на эту же кнопку повторно.
РУССКИЙ
SAFETY MEASURES
1. Never use this fan close to a water source (bathtub, washbasin, swimming pool...).
2. Never slip fingers, pencils or any other object through two grilles when the fan is in motion.
3. Disconnect the fan when moving it from one place to another.
4. Disconnect the fan prior to removing the grilles for cleaning.
5. Always ensure that the fan is placed on a stable surface to avoid it tipping over.
6. Never expose the fan to rain, water projections or damp.
7. If the fan's power cord becomes damaged, it must only be replaced by an After Sales
Service technician or another suitably qualified person to avoid any safety hazard.
ASSEMBL Y INSTRUCTIONS
• Please assemble correctly by the following orders when using.
1. Assembly The Stand
• Screw the iron plate out of the standing shaft in anticlockwise direction.
• Put the standing shaft into the stand.
• Screw the iron plate firmly from the bottom of the stand in clockwise direction and combinate the
standing shaft and the stand well.
2. The Whole Assembly
Link the fan main body and the standing shaft together by the fixing screw and then fix them.
Loosen the fixing screw and pull the electroplated pipe to the height needed and then fix it firmly.
3. Rear Net Assembly
Screw the blade fastening screw out in clockwise direction and screw the net fastening
screw out in anticlockwise direction.
Fix the rear guard onto the three pillars of the motor front shell.
Screw the net fastening screw tightly in clockwise direction.
4. The Assembly of Fan Blade
Put the fan blade onto the electrical axle centre and the axle centre bolt must be pressed to the end of
the concave notch at the back of the fan blade. They must be tallied completely.
Screw the screw into the electrical axle centre in anticlockwise direction and then fix it.
5. Fr
ont Net Assembly
• Put the hook of the front guard ring on the top of rear net.
• Put the rear net into front make them tally completely.
• Tighten the fastening screw of the lower of the front guard ring.
USING THE FAN
ON/SPEED:
Press the key it will be in wind speed state, the related indicator light will be on. The following diagram
shows the order of the wind flow: Weak >Middle > Strong
1 LOW SPEED
2 MEDIUM SPEED
3 HIGH SPEED
OFF ST
OP
Press the OFF key, all the working state will be cancel.
TIMER
Press this key it will be in wind speed state, the related indicator light will be on. The following diagram
shows the order of the time setting: 1 hour > 2 hours > 4 hours.
3
ENGLISH
6
1919.qxd 24.12.03 11:45 Page 6
