Fr-2
Carte mère MS-7526
Spécifications
Processeurs Supportés
- Intel
®
Core 2 Quad, Core 2 Duo, Pentium Dual-Core et Celeron
Dual-Core processeurs dans le paquet LGA775
- Intel
®
next generation 45 nm Multi-core CPU
(Pour plus d’informations sur le CPU, veuillez visiter
http://global.msi.com.tw/index.php?func=cpuform)
FSB supporté
- 1333/ 1066/ 800 MHz
Chipset
- North Bridge : chipset Intel
®
G43/ G45
- South Bridge : chipset Intel
®
ICH10/ ICH10R (optionnel)
Mémoire supportée
- 2 DDR2 DIMMs supportent DDR2 800/ 667 SDRAM (240pin / 1.8V
/ 4GB Max)
(Pour plus d’informations sur les composants compatibles, veuillez
visiter http://global.msi.com.tw/index.php?func=testreport)
LAN
- Supporte PCIE LAN 10/100/1000 Fast Ethernet par Realtek 8111C
Audio
- Puce intégrée par Realtek
®
ALC888
- 8-canaux audio flexibles avec détection de jack
- Compatible avec les spécifications d’Azalia 1.0
- Compatible avec les spécifications de Microsoft Vista Premium
IDE
- 1 port IDE par JMicron JMB368
- Supporte le mode Ultra DMA 66/100
- Supporte les modes d’opération PIO, Bus Master
SATA
- 4 ports SATAII par ICH10/ ICH10R (optionnel)
- Supporte le stockage et le taux de transfert jusqu’à 3 Gb/s
1394 (optionnel)
- Supporte 1394 par JMicron JMB381
RAID (optionnel)
- SATA1~4 supportent les modes RAID 0/ 1/ 5/ 10/ JBOD par
ICH10R (optionnel)
