Gettng Started
Manboard Speccatons
Processor Support
Intel
®
Core
TM
7/ Core
TM
5 /Core
TM
3/ Pentum
®
/ Celeron
®
processor n the LGA1155
package
(For the latest nformaton about CPU, please vst
http://www.ms.com/servce/cpu-support)
Chpset
Intel
®
H61 chpset
Memory Support
2 DDR3 DIMMs support DDR3 1333/ 1066 DRAM (16GB Max)
Supports Dual-Channel mode
(For more nformaton on compatble components, please vst
http://www.ms.com/servce/test-report)
LAN
Supports LAN 10/100/1000 by Realtek
®
RTL8111E
Audo
HD audo codec ntegrated by Realtek
®
ALC887
Flexble 8-channel audo wth jack sensng
SATA
4 SATA 3Gb/s (SATA1~4) ports by Intel
®
H61 PCH (PH61A-P35 (B3)/ PH61-P33
(B3))
2 SATA 3Gb/s (SATA1~2) ports by Intel
®
H61 PCH (PH61-SP35 (B3))
2 SATA 6Gb/s (SATA5~6) ports ASMeda
®
ASM1061 (PH61A-P35 (B3))
USB 3.0 (PH61A-P35 (B3))
2 USB 3.0 rear IO ports by ASMeda
®
ASM1042
Connectors
Back panel
1 PS/2 keyboard port
1 PS/2 mouse port
2 USB 3.0 ports (PH61A-P35 (B3))
4 USB 2.0 ports (PH61A-P35 (B3)/ PH61-SP35 (B3))
6 USB 2.0 ports (PH61-P33 (B3))
1 VGA port*
1 DVI-D port* (PH61A-P35 (B3)/ PH61-SP35 (B3))
1 LAN port
6 exble audo ports (PH61A-P35 (B3)/ PH61-P33 (B3))
3 exble audo ports** (PH61-SP35 (B3))
*(The VGA & DVI-D ports only work wth Integrated Graphcs Processor)
**(If the manboard, whch equps 3 audo jacks, wants to reach the 8-channel sound
eect, the 7th and 8th channels must be output from front panel.)
■
■
■
■
■
■
■
■
■
■
■
■
-
-
-
-
-
-
-
-
-
-
