BIOS Setup
MS-7732
Chapter 3
3-13
BIOS Setup
MS-7732
Chapter 3
OC Gene Button Operaton
Ths eld s used to enable/ dsable OC Gene functon.
DRAM Frequency
Ths settng controls the memory frequency to enable the memory to run at derent
frequency combnatons.
Adjusted DRAM Frequency
It shows the adjusted DRAM frequency. Read-only.
DRAM Tmng Mode
Select whether DRAM tmng s controlled by the SPD (Seral Presence Detect) EE
-
PROM on the DRAM module. Settng to [Auto] enables DRAM tmngs and the followng
“Advanced DRAM Conguraton” sub-menu to be determned by BIOS based on the
conguratons on the SPD. Selectng [Lnk] or [Unlnk] allows users to congure the
DRAM tmngs and the followng related “Advanced DRAM Conguraton” sub-menu
manually.
Advanced DRAM Conguraton
Press <Enter> to enter the sub-menu.
Command Rate
Ths settng controls the DRAM command rate.
tCL
Ths controls the CAS latency, whch determnes the tmng delay (n clock cycles)
before SDRAM starts a read command after recevng t.
tRCD
When DRAM s refreshed, both rows and columns are addressed separately. Ths
setup tem allows you to determne the tmng of the transton from RAS (row ad
-
dress strobe) to CAS (column address strobe). The less the clock cycles, the faster
the DRAM performance.
tRP
Ths settng controls the number of cycles for Row Address Strobe (RAS) to be
allowed to precharge. If nsucent tme s allowed for the RAS to accumulate ts
charge before DRAM refresh, refreshng may be ncomplete and DRAM may fal
to retan data. Ths tem apples only when synchronous DRAM s nstalled n the
system.
▶
▶
▶
▶
▶
▶
▶
▶
▶
