2-16

Hardware Setup

MS-7732

Chapter 2

Hardware Setup

MS-7732

Chapter 2

S/PDIF-Out Connector: JSP1

Ths connector s used to connect S/PDIF (Sony & Phlps Dgtal Interconnect Format)

nterface for dgtal audo transmsson.

3.VC

2.SPDIF

.Ground

* The MB layout n ths gure s for reference only.

S/PDIF-Out Bracket (optonal)

Seral Port Connector: JCOM1

Ths connector s a 16550A hgh speed communcaton port that sends/receves 16

bytes FIFOs. You can attach a seral devce.
