Tp-Link T2600G-28TS (TL-SG3424) [105/355] Configuration procedure

UNIT:

Click 1 to configure the physical ports. Click LAGS

to configure the

link aggregation groups.



Private VLAN Port Table

Port ID:

Displays the port number.

Port Type:

Displays the corresponding Port Type.

Note:

1. A Host Port can only join to one Private VLAN.

2. A Promiscuous Port can only join to one Primary VLAN.

3. If you want to add a Promiscuous port to different Private VLANs with the same Primary VLAN,

you need to add the Promiscuous port to any one of these Private VLANs.

Configuration Procedure:

Step Operation Description

Create Private VLAN. Required. On the VLAN→Private VLAN→PVLAN Config

page, Enter the Primary VLAN and Secondary VLAN, select

one type of secondary VLAN and then click the Create

button.

Add ports to Private VLAN Required. On the VLAN→Private VLAN→Port Config

page, select the desired ports and configure the port types

and click the Apply button.

Delete VLAN. Optional. On the VLAN→Private VLAN→PVLAN Config

page, select the desired entry to delete the corresponding

VLAN by clicking the Delete button.

6.10 Application Example for Private VLAN

 Network Requirements

 Switch C is connecting to switch A, switch A is connecting to switch B;

 Switch A is connecting to VLAN4 and VLAN5;

 Switch B is connecting to VLAN5 and VLAN8;

 For switch C, packets from switch A and switch B have no VLAN tags. Switch C needs not to

consider the VLANs of switch A and switch B;
