Tp-Link T2500-28TC (TL-SL5428E) [176/316] Querier config

166

Figure 10-18 Static Multicast

The following entries are displayed on this screen:



Static Multicast Config

VLAN ID: Enter the VLAN ID.

Multicast IP: Enter the multicast IP address.

Member Ports: Enter the member ports of the static multicast group.



Static Multicast List

Select: Select the static multicast group you want to change.

VLAN ID: Displays the VLAN ID.

Multicast IP: Displays the multicast group IP address.

Member Ports:

Displays the member ports of the static multicast

group.

10.2.6 Querier Config

In an IPv6 multicast network that runs MLD, a Layer 3 multicast device works as an MLD querier to

send out MLD queries and manage the multicast table. But MLD is not supported by the devices in

Layer 2 network. MLD Snooping Querier can act as an MLD Router in Layer 2 network. It can help

to create and maintain multicast forwarding table on the switch with the Query messages it

generates.

Choose the menu Multicast→MLD Snooping→Querier Config to load the following page.

Figure 10-19 Querier Config
