Tp-Link T2500-28TC (TL-SL5428E) [196/316] Configuration procedure of voice vlan
![Tp-Link T2500-28TC (TL-SL5428E) [196/316] Configuration procedure of voice vlan](/views2/1210074/page196/bgc4.png)
186
Configuration Procedure of Voice VLAN:
Step Operation Description
1
Configure the link type of
the port
Required. On VLAN→802.1Q VLAN→Port Config page,
configure the link type of ports of the voice device.
2
Create VLAN Required. On VLAN→802.1Q VLAN→Port Config page,
click the Create button to create a VLAN.
3
Add OUI address Optional. On QoS→Voice VLAN→OUI Config page, you
can check whether the switch is supporting the OUI
template or not. If not, please add the OUI address.
4
Configure the parameters
of the ports in voice VLAN.
Required. On QoS→Voice VLAN→Port Config page,
configure the parameters of the ports in voice VLAN.
5
Enable Voice VLAN Required. On QoS→Voice VLAN→Global Config page,
configure the global parameters of voice VLAN.
Return to CONTENTS
