1. Introduction

Components

CS72D Front View

CS74D Front View

No. Component Description

1Port

Selection

Pushbuttons

For manual port selection, press a port selection pushbutton

to bring the KVM focus to the computer attached to its

corresponding port.

See Manual Switching, page 11 for more details.

2 Port LEDs The Port LEDs are built into the Port Selection Switches.

 Flashes indicate that the computer attached to the

corresponding port has the KVM focus and is being

accessed in Auto Scan Mode (see Auto Scanning,

page 14).

 Lights steady to indicate that the computer attached to its

corresponding port is the one that has the KVM focus.

 The LED is off when the port is not selected.
