CS72U / CS74U User Manual

Hardware Requirements

Console

 A VGA compatible monitor capable of the highest possible resolution

 A USB mouse

 A USB keyboard

 Microphone and Speakers (optional)

Note: Use a keyboard that supports your operating system (OS). For

example: use a Mac keyboard when you are working on a Mac OS,

and use Sun keyboard when you are working on a Sun OS.

Computers

 A VGA port

Note: The quality of the display is affected by the quality of the VGA

display card. For best results, we recommend you purchase a high

quality product.

 Audio ports (optional)

 Type A USB ports

Cables

Only KVM cable sets which are specifically designed to work with this switch

may be used to link to the computers. Two (CS72U) or four (CS74U) cable sets

are provided with this package. To order further cable sets, please see table,

below:

Note: The quality of the display is affected by the quality and length of the

cables. Please use the cables provided in the package to have the best

quality. If you need additional cable sets, please contact your dealer to

purchase the appropriate ones for your switch.

Connectors Length Part Number

USB 1.2 m LIN5-23X5-X31G (1.2M)

USB 1.8 m LIN5-23X5-X32G (1.8M)
