CS72U / CS74U User Manual

Specifications

Note: Do not connect a KVM Extender to the KVM Switch to extend the

distance as doing this deteriorates the video quality.

Function CS72U CS74U

Computer Connections 2 4

Port Selection Front Panel Pushbuttons

Connectors Console

Ports

Keyboard 1 x USB Type A Female (Black)

Video 1 x HDB-15 Female (Blue)

Mouse 1 x USB Type A Female (Black)

Microphone

1 x mini stereo Jack Female (Pink)

Speaker

1 x mini stereo Jack Female (Green)

KVM Ports 2 x SPHD-18 Female

(Yellow)

4 x SPHD-18 Female

(Yellow)

Power 1 x DC Jack (Spare)

LEDs On Line 2 (Orange) 4 (Orange)

Selected 2 (Green) 4 (Green)

Button Selected 2 x Pushbuttons 4 x Pushbuttons

Video 2048 x 1536 @ 60 Hz; DDC2B

Power Consumption DC5V, 0.5W

Environment Operating Temp. 0–50ºC

Storage Temp. -20–60ºC

Humidity 0–80% RH, Non-condensing

Physical

Properties

Housing Metal

Weight 0.45 kg 0.64 kg

Dimensions (L x W x H) 13.00 x 7.45 x 4.20 cm 20.00 x 7.45 x 4.20 cm
