- 15 -

CS-84A Hotkey Operation

Hotkey operations for the CS-84A begin by pressing and

releasing the [Alt+Ctrl+Shift] combination.

Note: The combination must all be on the same side (i.e.,

[LeftAlt+LeftCtrl+LeftShift] or

[RightAlt+RightCtrl+RightShift]).

The CS-84A provides the following Hotkey Port Selection

features:

 Selecting the active port

 Auto Scan Mode

 Last/Next Mode

Selecting the Active Port

Each KVM port is assigned a numeric ID (1–4). You can directly

access any computer on the installation with a Hotkey

combination that specifies the ID of the KVM port that the

computer is connected to. The steps involved are:

1. Press and release [Alt+Ctrl+Shift].

2. Key in the appropriate Port ID number (1, 2, 3, or 4).

3. Press [Enter] to complete your selection.

Auto Scan Mode

The CS-84A’s Auto Scan feature automatically cycles the KVM

focus through the four computers at regular five second intervals

so that you can monitor their activity without switching from port

to port manually. To invoke Auto Scan Mode, do the following:

1. Press and release [Alt+Ctrl+Shift].

2. Press 0 (zero).

3. Press [Enter].
