![Aten CS82A [18/20] Specifications](/views2/1211136/page18/bg12.png)
- 18 -
Specifications
Function CS-82A CS-84A
Computer Connections 2 4
Port Selection Pushbuttons, Hotkeys
Console
Connectors
Keyboard 1 x 6-pin Mini-DIN Female (Purple)
Video 1 x HDB-15 Female
Mouse 1 x 6-pin Mini-DIN Female (Green)
Computer
Connectors
Keyboard 2 x 6-pin Mini-DIN
Female (Purple)
4 x 6-pin Mini-DIN
Female (Purple)
Video 2 x HDB-15 Male 4 x HDB-15 Male
Mouse 2 x 6-pin Mini-DIN
Female (Green)
4 x 6-pin Mini-DIN
Female (Green)
Switches 2 x Pushbutton 4 x Pushbutton
LEDs On Line 2 (Orange) 4 (Orange)
Selected 2 (Green) 4 (Green)
Emulation Keyboard / Mouse PS/2
Video 1920 x 1440; DDC2B
Scan Interval 3, 5, 10, 20 seconds 5 seconds
Power Consumption DC9V, 1.08W DC9V, 1.17W
Environment Operating
Temperature
0–50ºC
Storage Temperature -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.42 kg 0.64 kg
Dimensions
(L x W X H)
14.00 x 8.70 x 5.50 cm 21.00 x 8.70 x 5.50 cm
