CE600 / CE602 User Manual

Features

 Local and Remote Units connect at distances up to 60 m using Cat 5e

cable

 Allows access to a computer or KVM installation from a remote console

(up to 60m)

 Control your system from the remote console (USB keyboard, USB mouse

and DVI interface monitor)

 Supports DVI-D interface and allows transmission of DVI dual-link

signals (CE602)

 Features ATEN technology that allows A/V transmission over one Cat 5e

cable

 Enable HDCP, RS-232, microphone and dual link signals by adding a

second Cat 5e cable (CE602 only)*

 Manual compensation control to adjust signal strength in order to

compensate for distance

 RS-232 serial ports – connect to a serial terminal, or serial devices such as

touchscreens and barcode scanners (Baud Rate 115200 bps)

 Audio Enabled – supports stereo speakers and microphone

 Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage

15KV)

 Supports Wide Screen formats

 Superior video quality of up to 2560 x 1600 @ 60 Hz (DVI Dual Link) at

40 m (CE602 only); 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768 @ 60 Hz at

60 m – get an excellent, crisp image on your screen over long distance

transmissions

 Hot pluggable

 Rack mountable

 Easy to install – no software required – connecting cables to the devices is

all it takes

 Firmware upgrade

 Supports Wide Screen formats **

Note:*The length of the two Cat 5e cables must be the same.

**The EDID data for a widescreen is sent from the local video output

port. For widescreen modes and displays connect the monitor to the

local video output port or use an ATEN EDID emulator.
