Aten KN4132v [252/316] Options

KVM Over the NET™ User Manual

234

Options

Network Retry allows you to set the number of seconds that the Log Server

should wait before attempting to connect if its previous attempt to connect

failed. When you click this item, a dialog box, similar to the one below,

appears:

Key in the number of seconds, then click OK to finish.

Help

From the Help menu, click Contents to access the online Windows Help file.

The help file contains instructions about how to setup, operation and

troubleshoot the Log Server.
