Chapter 1. Introduction
3
Requirements
LCD Console
The LCD console supports most ATEN DVI KVM switches. If you are
unsure whether your switch is supported or not, check with your dealer.
The integrated LCD monitor's maximum resolution is 1920 x 1080
@60Hz. Make sure that none of the resolution settings of the connected
computers exceed the LCD monitor's maximum resolution.
External Console
A VGA, SVGA, MultiSync, DVI, or HDMI monitor capable of displaying
the highest resolution provided by any computer in the installation
USB keyboard and mouse
Cables
For optimum signal integrity and to simplify the layout, we strongly
recommend that you use high quality custom cable sets available in varying
lengths, described in the table below, which can be purchased from your dealer.
Length (m) Part Number
1.80 2L-7D02U
3.00 2L-7D03U
5.00 2L-7D05U
1.80 2L-7D02UH
