CL6700MW User Manual

LCD OSD Configuration

The LCD Buttons

The LCD OSD allows you to set up and configure the LCD display. Four

buttons are used to perform the configuration, as described in the table, below:

The Adjustment Settings

An explanation of the LED OSD adjustment settings is given in the table

below:

Button Function

 When you have not entered the LCD OSD Menu function,

pressing this button invokes the Menu function, and brings up

the Main Menu.

 When you have entered the LCD OSD Menu function, and

have reached a setting choice with the navigation buttons,

pressing this button brings up its adjustment screen.

When navigating through the menus, this button moves you Right

or Up. When making an adjustment, it increases the value.

When navigating through the menus, this button moves you Left

or Down. When making an adjustment, it decreases the value.

EXIT

 When you have not entered the LCD OSD Menu function,

pressing this button performs an auto adjustment. An auto

adjustment automatically configures all the settings for the

LCD panel to what the OSD considers their optimum values to

be.

 When you have entered the LCD OSD Menu function, pressing

this button exits the current menu and returns you to the

previous menu. Use it to leave an adjustment menu when you

are satisfied with the adjustment you made.

 When you are at the Main Menu, pressing this button exits the

LCD OSD.

Setting Explanation

Brightness Adjusts the background black level of the screen image.

Contrast Adjusts the foreground white level of the screen image.

Phase If pixel jitter or horizontal line noise is visible on the display,

your LED may have the wrong phase setting. Adjust the

phase setting to eliminate these problems.

Clock If vertical banding is visible on the display, your LED may

have the wrong clock setting. Adjust the clock setting to

eliminate vertical banding.

H-Position Positions the display area on the LED panel horizontally

(moves the display area left or right).
