CL6700MW User Manual
20
4. If the KVM switch connected to the CL6700MW uses the [Ctrl] [Alt]
[Shift] combination to invoke its hotkey mode, you won't be able to
access any of its hotkey operations because the CL6700MW will
capture the combination for console selection first.
