CS1768 / CS1788 User Manual
Features
One USB console controls eight Single Link DVI (CS1768) / Dual Link
DVI (CS1788) or VGA computers and two additional USB 2.0 devices
Supports both digital (DVI) and analog (VGA) video – mixed operation
possible
Cascadable to three levels – control up to 512 computers
Multi-view feature – stack up to four CS1768 / CS1788 units and display
video from up to four monitors (dual view / triple view / quad view)
2-port USB 2.0 hub built in*
Fully compliant with the USB 2.0 specification
Computer selection via front panel pushbuttons, hotkeys, and multilingual
on-screen display (OSD)
Independent switching of KVM and USB focus
Broadcast mode – allows you to send commands from the console to all
computers to perform operations simultaneously.
OSD Backup/Restore feature – enables the administrator to back up the
switch’s configuration and user profile information
Firmware upgradable
DVI digital and analog monitor support – fully compliant with the DVI
specifications
Video DynaSync
TM
– exclusive ATEN technology eliminates boot-up
display problems and optimizes resolution when switching between ports
Superior video quality – 1920 x 1200 (Single Link DVI – CS1768) / 2560
x 1600 (Dual Link DVI – CS1788); 2048 x 1536 (VGA); DDC2B
Supports widescreen resolutions
Audio enabled – full bass response provides a rich experience for 2.1
channel surround sound systems
Console audio ports on front panel for easy access
Auto Scan Mode for monitoring all computers
HDCP compatible
Multiplatform support – Windows, Linux, Mac**, Sun**
2
