4. OSD Operation

(Continued from previous page.)

Setting Function

SET QUICK This function lets the administrator select which ports to include as

VIEW PORTS quick view ports.

 To select/deselect a port as a quick view port, double-click the

port, or use the navigation keys to move the highlight bar to it,

then press [Spacebar].

 When a port has been selected as a quick view port, an icon dis-

plays in the QV column of the LIST on the main screen. When a

port is deselected, the icon disappears.

 If one of the quick view options is chosen for the LIST view (see

F2 LIST, page 36), only a port that has been selected here

will display on the list.

 If one of the quick view options is chosen for auto-scanning

(see SCAN/SKIP MODE, page 38), only a port that has been

selected here will be auto-scanned.

The default has no ports selected for quick view.

SET This function allows the administrator to define the operating

OPERATING system for the computer connected to each KVM port. The default

SYSTEM is WIN (PC compatible).

To set the port operating system:

1. From the list, select the port for which you wish to set the com-

puter's operating system.

2. Set the operating system by pressing [Spacebar] to cycle

through WIN, MAC, SUN, or OTHER .

3. Press [Esc] to exit. The operating system you selected is

assigned to the KVM port.

FIRMWARE In order to upgrade the CS1768 / CS1788 firmware (see page 59),

UPGRADE you must first enable Firmware Upgrade mode with this setting.

When you bring up this menu, the current firmware version levels

are displayed. Select Y to enable Firmware Upgrade mode, or N to

leave this menu without enabling it.

KEYBOARD Sets the language for the computer keyboard attached to the KVM

LANGUAGE

port. To select a keyboard language, double-click it, or use the

navigation keys to move the highlight bar to it, then press [Enter].

Choices are: AUTO (default), ENGLISH (US), ENGLISH (UK),

GERMAN (GER.), GERMAN (SWISS), FRENCH, HUNGARIAN,

ITALIAN, JAPANESE, KOREAN, RUSSIAN, SPANISH, SWEDISH,

TRADITIONAL CHINESE, and SIMPLIFIED CHINESE.

(Continues on next page.)
