Aten CS1768 [15/84] Cables
![Aten CS1768 [15/84] Cables](/views2/1211406/page15/bgf.png)
1. Introduction
Cables
Only custom USB DVI KVM cable sets, which are specifically designed
to work with this switch, may be used to link to the computers. Two cable
sets are provided with this package.
Note: The quality of the display is affected by the quality and length of the
cables. If you need additional cable sets, please contact your dealer
to purchase the appropriate ones for your switch.
Type Length Part Number
USB DVI-D Single
Link
1.8 m 2L-7D02U
3.0 m 2L-7D03U
5.0 m 2L-7D05U
USB DVI-I Single
Link
1.8 m 2L-7D02UI
3.0 m 2L-7D03UI
USB DVI-D Dual
Link
1.8 m 2L-7D02UD
3.0 m 2L-7D03UD
5.0 m 2L-7D05UD
USB DVI-I Single Link for CS1768 / USB DVI-D Dual Link for CS1788
For multi-view installations, standard USB Type A to USB Type B cables
and standard DVI cables are also required.
5
