Aten VS881 [11/15] Installation

- 11 -

Installation

Refer to the installation diagram on the next page (the numbers

in the diagram correspond to the numbers of the steps) and do

the following:

1. Make sure that power to all the devices you will be connecting

up have been turned off.

2. Plug the monitor or digital projector cable into the unit’s

Monitor port.

3. Plug one end of a video cable (see Cables, page 7), into any

available video port on the unit; plug the other end into the

computer’s video output port.

4. Plug the power adapter (supplied with this package) into an

AC source; plug the power adapter cable into the unit’s Power

Jack.

5. Plug the IR Receiver cable into the IR Receiver port at the

front of the main unit.

6. Power On all equipment.

1. Make sure that the power to any device that you connect

to the installation has been turned off. You must unplug the

power cords of any computers that have the Keyboard

Power On function.

2. Make sure that all devices you will be installing are

properly grounded.

3. Do not look directly at the light coming from the fiber optic

connectors and cable as it is harmful to the eyes.
