- 13 -

Port Selection

Manual Port Up / Port Down

Use the Port Up and Port Down buttons, located on the top of the

VS881 unit, to cycle the video focus to the port you want.

A Port LED changes from ORANGE to GREEN to indicate that

the computer connected to its corresponding port has the video

focus.

IR Port Up / Port Down

The video focus can also be cycled among the computers using

the Port Up and Port Down buttons of the IR Remote Control Unit

(refer to page 10).

Note: The IR Remote Control Unit is used in conjunction with the

external IR Receiver (see the diagram on page 12).

IR Direct Port Selection

Instead of cycling among the individual computers one-by-one, a

computer can be directly selected by pushing the button on the

Remote Control Unit that corresponds to its port number (1-8) on

the main unit.

The selected port’s LED changes from ORANGE to GREEN to

indicate that the computer connected to its corresponding port

has the video focus.

Note: For optimum performance make sure that there is a clear

line-of-site between the handset and the receiver.
