- 10 -
Installation
Single Stage Installation
In a Single Stage installation no additional Video Splitters are
cascaded down from the first unit. To set up a single stage
installation, do the following:
1. Use a high density HDB-15 male/female VGA cable (Part No.
2L-2401) to connect the computer's video port to the Video In
port of the Video Splitter.
2. Use high density HDB-15 male/female VGA cables (Part No.
2L-2401) to connect the Video Out ports of the Video Splitter
to the monitors.
3. Plug the power adapter into an AC source; plug the power
adapter cable into the video splitter.
4. Power up the Video Splitter; power up the monitors; power up
the computer.
Make sure that all devices you will be connecting up are
properly grounded.
