B85H3-M7 USER MANUAL

Chapter 1

• AMI BIOS with 64Mb SPI Flash ROM

• Supports Plug and Play, STR(S3)/STD(S4)

• Supports Hardware Monitor

• Supports ACPI & DMI

• Audio, LAN, can be disabled in BIOS

• Supports Dual/Triple Display (depends on display output)

• F7 hot key for boot up devices option

• Supports Pgup clear CMOS Hotkey (Has PS2 KB Model only)

• Supports Multi-Language

• Supports AC’97/HD Audio auto detect (default)

System BIOS

Form Factor

• Micro-ATX Size, 225mm x 180mm
