A68F2P-M2 USER MANUAL

Chapter 1

• AMI BIOS with 32Mb SPI Flash ROM

- Supports Plug and Play

- Supports ACPI & DMI

- Supports Hardware Monitor

- Supports STR (S3)/STD (S4)

- Supports Audio, LAN, can be disabled in BIOS

- F7 hot key for boot up devices option

- Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only)

System BIOS

Form Factor

• Micro-ATX Size, 225mm x 200mm

• 1 x Speaker header

• 1 x Clear CMOS jumper

• 1 x Parallel port header (LPT)
