ECS Elitegroup CDC-I [6/56] Chipset
![ECS Elitegroup CDC-I [6/56] Chipset](/views2/1212380/page6/bg6.png)
2
Introducing the Motherboard
Feature
Processor
• D2700 supports “Hyper-Threading” technology CPU
“Hyper-Threading” technology enables the operating system into thinking it’s
hooked up to two processors, allowing two threads to be run in parallel, both on
separate “logical” processors within the same physical processor.
The Intel
®
NM10 chipset is based on an innovative and scalable architecture
with proven reliability and performance.
Chipset
• Enhanced DMA Controller, interrupt controller, and time functions
• Integrated SATA 3.0 Gb/s Host Controller
• Integrated USB 2.0 Host Controller
• Intel
®
Atom D2700/D2500/D2550 or other CPU
Memory
• Supports DDR3 1066 SO-DIMM with single-channel architecture
• Accommodates two unbuffered DIMMs
• 2 x 204-pin DDR3 SODIMM sockets support up to 4 GB
Onboard LAN (optional)
The onboard LAN provides the following features:
• Supports PCI Express
TM
1.1
• Integrated 10/100 transceiver
• Wake-on-LAN and remote wake-up support
• Supports PCI Express
TM
1.1
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
The motherboard comes with the following expansion options:
• One 32-bit PCI slot
• Two 7-pin SATA connectors
Expansion Options
This motherboard may support either of the following Audio chipsets:
• 5.1 Channel High Definition Audio Codec
• ADCs support 44.1k/48k/96kHz sample rate
• Meets Microsoft WLP 3.10 Vista premium and mobile PCs audio
requirements
• Direct Sound 3D
TM
compatible
Audio
