26
Using BIOS
CPU Smart FAN Control (Enabled)
This item allows you to enable/disable the control of the CPU fan speed by changing
the fan voltage.
Version 2.02.1205. Copyright (C) 2012, American Megatrends, Inc.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Temperature 60
Low Limit Temperature 37
High Limit PWM 200
Low Limit PWM 56
SYS Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Temperature 60
Low Limit Temperature 37
High Limit PWM 200
Low Limit PWM 56
Main Advanced Chipset Frequency/Voltage Control Boot Security Save & Exit
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
Enable CPU SmartFan
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paeameters for critical voltages, temperatures and fan speeds.
-=- PECI Mode -=-
Offset to TCC Activation Temp : -27
CPU Tct1 : +61
System temperature : +35 C
CPU FAN : 4249 RPM
SYS FAN : N/A
VDIMM : +1.531 V
Smart Fan Function
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
Main Advanced Chipset Frequency/Voltage Control Boot Security Save & Exit
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
