ECS Elitegroup HDC-I2/E-350D (V1.0) [38/64] Using bios
![ECS Elitegroup HDC-I2/E-350D (V1.0) [38/64] Using bios](/views2/1212409/page38/bg26.png)
34
Using BIOS
South Bridge
Scroll to this item and press <Enter> to view the following screen.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Specify what state to go to
when power is re-applied after
a power failure (G3 state).
SB Chipset Configuration
Restore AC Power Loss [Power Off]
Azalia HD Audio [Enabled]
Case Open Warning [Disabled]
Chassis Opened [No]
Restore AC Power Loss (Power Off)
This item specifies what state to go to when power is re-applied after a power failure
(G3 state).
Azalia HD Audio (Enabled)
This item enables or disables Azalia HD audio.
Press <Esc> to return to the chipset menu page.
Case Open Warning (Disabled)
This item enables or disables the warning if the case is opened up, and the item below
indicates the current status of the case.
Chassis Opened (No)
This item indicates whether the case has been opened.
Main Advanced Chipset Frequency/Voltage Control Boot Security Save & Exit
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
