28
Using BIOS
Power Management Setup
Resume By PCI/PCI-E/Lan PME [Disabled]
Resume By USB (S3) [Disabled]
EUP Function [Enabled]
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
About Resume by PCI/PCI-E/Lan
PME
Power Management Setup
This page sets up some parameters for system power management operation.
Resume By PCI/PCI-E/Lan PME (Disabled)
The system can be turned off with a software command. If you enable this item, the
system can automatically resume if there is an incoming call on the PCI Modem or
PCI LAN card. You must use an ATX power supply in order to use this feature. Use
this item to do wake-up action if inserting the PCI card.
Resume By USB (S3) (Disabled)
This item allows you to enable/disable the USB device wakeup function from S3
mode.
Main Advanced Chipset Frequency/Voltage Control Boot Security Save & Exit
EUP Support (Enabled)
This item allows user to enable or disable EUP support.
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
Press <Esc> to return to the Advanced Menu page.
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
