Chapter 2
13
B85H3-M6 USER MANUAL
Recommend memory configuraon
Due to Intel CPU spec definion, please follow the table above for
recommended memory configuraon.
1. For best performance and compability, we recommend that users give
priority to the white DIMMs (DDR3_2/DDR3_4) when installing DIMMs.
2. We suggest users not to mix memory type. It is recommended to use the
same brand and type memory on this motherboard.
Model
Sockets
DDR3_1
DDR3_2
DDR3_3
DDR3_4
1 DIMM ~ Populated ~ ~
1 DIMM ~ ~ ~ Populated
2 DIMMs
~ Populated ~ Populated
3 DIMMs
Populated Populated ~ Populated
3 DIMMs
~ Populated Populated
Populated
4 DIMMs
Populated Populated Populated
Populated
