Chapter 2

B85H3-M6 USER MANUAL

2-4-5. Connecting Optional Devices

Refer to the following for information on connecting the motherboard’s optional

devices:

N o . Compo nents No. Comp on ents

1CASE 5USB3F

2 LPT 6 F_USB1~2&F_USB3

3COM1~27F_AUDIO

4SATA3_1~4 & SATA 5~~ ~~
