35
Using BIOS
Onboard FDC Controller (Enabled)
This option enables the onboard floppy disk drive controller.
Onboard Serial Port 1/2 (3F8/IRQ4, 2F8/IRQ3)
This option is used to assign the I/O address and interrupt request (IRQ) for onboard serial
port 1/2.
UART Mode Select (IRDA)
This field is available if the Onboard Serial Port 2 field is set to any option but Disabled.
. UART Mode Select enables you to select the infrared communication protocol-IrDA,
ASKIR or SCR.
UR2 Duplex Mode (Half)
This field is available when UART Mode is set to either ASKIR or IrDA. This item enables
you to determine the infrared function of the onboard infrared chip. The options are Full
and Half (default). Full-duplex means that you can transmit and send information
simultaneously. Half-duplex is the transmission of data in both directions, but only one
direction at a time.
Onboard Parallel Port (378/IRQ7)
This option is used to assign the I/O address and interrupt request (IRQ) for the onboard
parallel port.
Parallel Port Mode (ECP)
Enables you to set the data transfer protocol for your parallel port. There are four options:
SPP (Standard Parallel Port), EPP (Enhanced Parallel Port), ECP (Extended Capabilities
Port) and ECP+EPP.
SPP allows data output only. Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) are bi-directional modes, allowing both data input and output. ECP and EPP modes
are only supported with EPP- and ECP-aware peripherals.
ECP Mode Use DMA (3)
When the onboard parallel port is set to ECP mode, the parallel port can use DMA 3 or
DMA 1.
SuperIO Device (Press Enter)
Phoenix-AwardBIOS CMOS Setup Utility
SuperIO Device
Scroll to this item and press <Enter> to view the following screen:
Item Help
Menu Level
Onboard FDC Controller [Enabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Serial Port 2 [2F8/IRQ3]
UART Mode Select [IRDA]
UR2 Duplex Mode [Half]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [ECP]
ECP Mode Use DMA [3]
Press <Esc> to return to the Integrated Peripherals page.
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
