Multi-Language Translation
Русский
Встроенный сетевой адаптер LAN (опционально)
• Совместимость с технологией 10/100/1000BASE-T IEEE 802.3
• Поддержка интерфейсов GMII, TBI, RGMII, RTBI, a также серийного
интерфейса SGMII
• Совместимость с технологией IEEE 802.3u Auto-Negotiation
• Предотвращает формирование фиктивных адресов IP выходящих
пакетов и позволяет осуществлять регистрацию и конфигурацию
Встроенный сетевой адаптер LAN обладает следующими характеристиками:
Интегрированный вход/выход
Плата снабжена полным набором портов входа/выхода и разъемов:
• Два порта PS/2 для подключения мыши и клавиатуры
• Один серийный порт
• Один параллельный порт
• Четыре порта USB
• Один порт LAN (опционально)
• Гнездо для подключения микрофона, гнезда аудио-входа и выхода
BIOS
Плата работает под Award BIOS, который позволяет пользователю конфигурировать
различные характеристики системы:
• Управление питанием
• Сигналы пробуждения системы
• Параметры CPU
• Время доступа для CPU и памяти
BIOS допускает также установку параметров для различных частот процессора.
Некоторые параметры платы и характеристики ее программного
обеспечения могут быть изменены без предварительного уведомления.
