36
Using BIOS
Power Management Setup
This option lets you control system power management. The system has various power-
saving modes including powering down the hard disk, turning off the video, suspending
to RAM, and software power down that allows the system to be automatically resumed
by certain events.
Item Help
Menu Level
Phoenix-AwardBIOS CMOS Setup Utility
Power Management Setup
ACPI Suspend Type (S3(STR)
Use this item to define how your system suspends. In the default, S3 (STR), the suspend
mode is a suspend to RAM, i.e., the system shuts down with the exception of a refresh
current to the system memory.
Video Off Method (DPMS Supported)
This item defines how the video is powered down to save power. This item is set to DPMS
(Display Power Management Software) by default.
HDD Power Down (Disabled)
The IDE hard drive will spin down if it is not accessed within a specified length of time.
HDD Down In Suspend (Disabled)
This item enables or disables whether the IDE hard drive to be down in suspend mode.
Soft-Off by PBTN (Instant-Off)
Under ACPI (Advanced Configuration and Power management Interface) you can create a
software power down. In a software power down, the system can be resumed by Wake Up
Alarms. This item lets you install a software power down that is controlled by the power
button on your system. If the item is set to Instant-Off, then the power button causes a
software power down. If the item is set to Delay 4 Sec. then you have
to hold the power button down for four seconds to cause a software power down.
Power On By Button (Enabled)
Enable or disable the function of waking up the system by the power-on button.
Power On By Mouse (Disabled)
Enable or disable the function of waking up the system by the mouse activity.
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
ACPI Suspend Type [S3(STR)]
Video Off Method [DPMS Support]
HDD Power Down [Disabled]
HDD Down In Suspend [Disabled]
Soft-Off by PBTN [Instant-Off]
Power On By Button [Enabled]
Power On By Mouse [Disabled]
Power On By Keyboard [Disabled]
KB Power ON Password Enter
Hot Key Power ON Ctrl-F1
PWRON After PWR-Fail [Off]
Resume By PCI PME [Enabled]
Resume By Ring [Disabled]
Power-On by Alarm [Disabled]
Day of Month Alarm 0
Time (hh:mm:ss) Alarm 0 : 0 : 0
AMD K8 Cool’n’Quiet control [Auto]
Hammer Fid control [StartUp]
