3
A960M-M3 USER MANUAL
Chapter 1
System BIOS
Form Factor • Micro-ATX Size, 244mm x 180mm
• AMI BIOS with 16Mb SPI Flash ROM
• Supports Plug and Play, STR(S3) / STD (S4), Hardware monitor,
Multi Boot
• Audio, LAN, can be disabled in BIOS
• Support Over-Clocking
• Support eBLU / Supoort eDLU / Supoort eOC
• Support ECS M.I.B III Utility
• F7 hot key for boot up devices option
Memory Voltage Adjustable
External Clock Adjustable
Multiple Frequency Adjustable
