Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for latest Intel
®
Core
TM
Famil
y
/Pentium
®
/Celeron
®
Processors
2. SPEAKER Speaker header
3. F_AUDIO Front panel audio header
4. CLR_CMOS Clear CMOS jumper
5. MINI-PCIE1X Mini PCI Express x1 slot (supports half-card)
6. SATA1~2 Serial ATA 3.0 Gb/s connectors
7. LCD_SEL1~2 LCD select jumpers
8. ME_DISABLE ME disable jumper
9. HDD_PW HDD power connector
10. ODD_PW ODD power connector
11. F_USB1 Front panel USB 2.0 header
12. TS Touch board header
13. CAMERA CCD header
14. MCR Card reader header
15. F_PANEL Front panel switch/LED header
16. SYS_FAN 4-pin system cooling fan connector
17. CPU_FAN 4-pin CPU cooling fan connector
18. LCD_OFF Panel switch
19. LVDS LVDS header (optional)
20. SO-DIMM1~2 240-pin DDR3 SO-DIMM sockets
21. FPD FPD power connector
1. CPU Socket
