ECS Elitegroup H61H-G11 (V7.0) [21/54] Installing the motherboard

Installing the Motherboard

ODD_PW: ODD power connector

This connector is used to provide power for the 0DD.

1 +5V

2 +5V

3 GND

Pin Signal Name

TS: Touch board header

1 +5V

2 USB_N

3 USB_P

Pin Signal Name

4 GND

5 Key

CAMERA: CCD header

1 +5V

2 USB_N

3 USB_P

Pin Signal Name

4 GND

5 Key

MCR: Card reader header

1 +5V

2 USB_N

3 USB_P

Pin Signal Name

4 GND

5 Key

LCD_OFF: Panel switch

This connector is used to provide power for the 0DD.

1 PWRDN

2 GND

Pin Signal Name
