Chapter 3

H61H2-M17 USER MANUAL

Press <Esc> to return to the M.I.B III Menu page.

Enhanced Intel SpeedStep Technology (Enabled)

This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep Tech-

nology).

Graphics Core Ratio Limit (22)

This item allows you to control the internal GFX Turbo ratio.

Graphics Voltage(1/256) (0)

This item allows you to adjust the internal GFX voltage.
