H61H2-M17 USER MANUAL

Chapter 1

• AMI BIOS with 64Mb SPI Flash ROM

- Supports Plug and Play

- Supports ACPI & DMI

- Supports S1 / STR (S3) /STD (S4)

- Supports Hardware monitor

- Audio, LAN, can be disabled in BIOS

- F7 hot key for boot up devices option

- Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only)

- Supports Dual/Triple Display

- Supports GUI UEFI

System BIOS

Form Factor • Micro ATX Size, 225mm x 170mm

- Supports eBLU*/eDLU/eSF*

AP Support

Note: *Microsoft .NET Framework 3.5 is required.
